Stable PET Monofilament Mesh

Polyester Filter Mesh

Polyester filter mesh is a PET monofilament mesh used for liquid filtration, powder screening, water treatment, chemical-compatible process filtration, and custom mesh components. It offers good dimensional stability, moisture resistance, and consistent mesh openings for repeatable particle separation.

Material

PET polyester monofilament

Micron Range

1-2000um

Formats

Roll / Sheet / Disc / Sleeve / Custom

Weave

Plain / Twill / Heat-set

Configure & Quote ->FAQ

Share this product

Key Specifications

Material

PET polyester monofilament

Micron Range

1-2000um

Formats

Roll / Sheet / Disc / Sleeve / Custom

Weave

Plain / Twill / Heat-set

Primary Use

Stable screening and filtration

Configuration Selector

Build Your Configuration

01Mesh Opening

02Supply Format

03Finish / Edge

04Quantity

pcs. No minimum for standard configurations.

Complete selection to see summary

Material:Polyester Monofilament Mesh

Mesh Opening:-

Supply Format:-

Dimensions:-

Flow Rate:-

Finish / Edge:-

Quantity:100 pcs

Complete All Selections

Technical Specifications

Full Spec Sheet

Material	PET polyester monofilament mesh
Filtration Mechanism	Surface screening by uniform mesh opening
Common Openings	1, 2, 5, 10, 20, 25, 40, 50, 75, 100, 150, 200, 300, 500, 800, 1000, 1500, 2000 um
Supply Format	Rolls, sheets, discs, sleeves, panels, and custom mesh parts

Mesh Specification Table

Polyester Filter Mesh Specifications

Product Code	Mesh Opening (um)	Open Area (%)	Mesh Count / cm	Mesh Count / inch	Thread Dia. (um)	Weight (g/m2)	Thickness (um)
PET1000-8	1000	62	8	20	250	117	480
PET640-13	640	69	13	33	140	56	280
PET580-12	580	49	12	30	250	175	480
PET430-16	430	46	16	40	200	149	370
PET390-18	390	48	18	45	170	120	310
PET355-19	355	49	19	50	180	137	340
PET320-24	320	57	24	60	100	56	160
PET280-24	280	44	24	60	140	110	260
PET270-24	270	41	24	60	150	126	280
PET250-32	250	62	32	80	64	31	95
PET230-29	230	46	29	75	120	98	215
PET216-32	216	46	32	80	100	75	170
PET200-39	200	62	39	100	55	30	88
PET190-36	190	45	36	90	90	68	150
PET185-39	185	53	39	100	70	46	115
PET153-48	153	52	48	120	55	36	88
PET150-43	150	42	43	110	80	65	133
PET145-48	145	47	48	120	64	47	94
PET140-48	140	44	48	120	70	56	115
PET130-55	130	51	55	140	55	40	87
PET120-55	120	44	55	140	64	53	97
PET100-63	100	40	63	160	55	48	95
PET90-63	90	32	63	160	64	62	115
PET90-72	90	42	72	180	48	39	78
PET84-72	84	35	72	180	55	53	90
PET82-77	82	40	77	195	48	42	80
PET77-80	77	37	80	200	48	44	78
PET75-77	75	33	77	195	55	57	88
PET62-90	62	32	90	230	48	50	78
PET58-100	58	33	100	250	40	37	62
PET50-120	50	35	120	300	31	27	49
PET48-110	48	28	110	280	40	40	64
PET46-120	46	30	120	300	34	35	55
PET38-140	38	27	140	350	31	30	48
PET34-140	34	22	140	350	34	39	54
PET32-150	32	23	150	380	31	32	49
PET30-165	30	25	165	420	27	29	44
PET28-150	28	18	150	380	34	42	55
PET26-165	26	18	165	420	31	37	48
PET25-181	25	20	181	460	27	31	43
PET17-200	17	11	200	500	31	45	58
PET30-55080C	30	-	181 / 48	460 \ 120	55 \ 80	-	-
PET30-55100C	30	-	181 / 43	460 \ 110	55 \ 100	-	-
PET50-10014C	50	-	110 / 22	280 \ 55	100 \ 140	-	-
PET60-14018C	60	-	26999	185 \ 30	140 \ 180	-	-

Mesh specifications are converted from the polyester filter mesh source sheet. Some composite mesh codes include combined construction values and should be confirmed before quotation.

Materials & Construction

How It Is Built

PET monofilament woven mesh

Polyester monofilament yarn creates consistent openings and stable fabric geometry for filtration and screening.

Suitable for conversion

Polyester mesh can be cut or sewn into rolls, sheets, discs, sleeves, panels, and custom parts for filtration equipment.

Applications

Industries & Use Cases

Water Treatment

*Pre-screening
*Suspended solids removal
*Reusable mesh inserts
*Equipment protection

Powder Screening

*Particle classification
*Granule screening
*Process mesh panels
*Material separation

Industrial Liquids

*Chemical-compatible straining
*Process liquid filtration
*Cooling water filtration
*Custom mesh components

Custom Options

MADE TO YOUR SPECIFICATION

Customize micron rating, dimensions, ring style, seam construction, and other details. MOQ starts from 100 pcs per SKU.

Submit Your Specification ->

Micron and mesh count selection

1 micron filter mesh, 2 micron filter mesh, 5 micron filter mesh, and other openings can be reviewed according to available PET mesh construction.

Custom roll width and length

Roll goods can be prepared for cutting, conversion, distributor programs, and equipment supply.

Custom mesh components

Polyester mesh discs, sleeves, sheets, panels, and drawing-based shapes are available.

Edge and seam treatment

Cut edge, ultrasonic cut, sewn edge, reinforced edge, and packaging options can be selected by part type.

FAQ

Common Questions

Can't find your answer? Send us a technical inquiry.

Ask a Question ->

Polyester filter mesh is a good choice when dimensional stability, moisture resistance, and consistent mesh openings are important for liquid filtration or screening.
